The multi-tray table counting machine is developed by Adhisakthi for counting and packing the tables through high sensitive sensors in containers and pouches.
Salient Features
- Confirms to cGMP Standards
- Sensors are specially designed for Tablet counting needs and those are imported.
- Three vibro feeders with online controls
- Online dust collection system
- Multichannel feeding upto 12 tracks
- Easy change over between different types & shapes of tablet
- Simple cleaning and refitting provision Precise in counting
- Speed would depend upon the size and shape of the tablets
- Online error indication system
- Suitable for a wide range of size and shapes of tablets
- Reduced noise level
- Pre programmable products memory
Optional Automation-Salient Feature
- Fully Automatic Container Feeding, Online Cleaning, Tablet counting, Filling, Capping, Induction sealing,
- Inspection and auto case packing systems.
- Tablet counting and filling vertical form fill and sealing machine (Pouches)
| Model |
TCM - 12 TRK
|
TCM -6 TRK
|
| Speed in Pcs/ Min |
1600 |
800 |
| No. of Feeding trays |
12 |
6 |
| Contact parts |
SS 316 |
SS 316 |
| Filling Accuracy |
+ 0.5% |
+0.5% |
| Hopper Capacity in Ltrs. |
20 |
15 |
| Power required in KW |
1.5 |
1 |
| Dimension (LxBxH) |
1350 x 1000 x 1900 |
1350x700x1900 |
| Weight (Approx ) in Lgs. |
900 |
750 |
| Speed of the machine depends upon the filling volume and nature of the product. |
Specifications are subject to change as a part of continuous improvement |
