  • Sigma mixer is a heavy duty mixer designed for dough mixing which is essential in the soaps , detergents, foods,
    rubber,chemical industries etc.
  • The Z arm or Sigma blade is designed for uniform mixing and criss cross flow of materials.
  • The blades rotate in the ratio of 1:1.5 ( 24 : 36 ) rpm
  • The mixer is supplied with jacket or without jacket as per the requirement of the customer.
  • We supply in different capacities with fully SS, Partly SS and fully MS constructions.
  • Discharge is by hydraulic door opening system or through screw rod system.
  • Heavy duty gear box and gears are used to withstand high viscous mixing.
  • Sigma blades are solidly casted, machined, x ray tested before fitting.
  • Minimal uniform gap is maintained between the trough and the blades.
Capacity Range
2000 kgs/ 1500 kgs /1000 kgs / 500 kgs / 250 kgs / 100 kgs / 50 kgs / 25 kgs / 10 kgs Batch Size

Model Aspro-SM-25 Aspro-SM-50 Aspro-SM-100 Aspro-SM-250 Aspro-SM-500 Aspro-SM-1000 Aspro-SM-2000
Batch Size (Kgs) 25 50 100 250 500 1000 2000
Contact Parts SS304/MS SS304/MS SS304/MS SS304/MS SS304/MS SS304/MS SS304/MS
Z-Arm Casted Casted Casted Casted Casted Casted Casted
Z-Arm ratio 1:1.5 1:1.5 1:1.5 1:1.5 1:1.5 1:1.5 1:1.5
Bottom Discharge Tilting Handle Operated Handle Operated Handle Operated Handle / Hydraulic
/Pneumatically Operated		 Hydraulic
/Pneumatically Operated		 Hydraulic
/Pneumatically Operated
Trough Size in mm 350 x 350 500 x 500 650 x 650 800 x 800 1000 x 1000 1200x 1200 1500x1500
Seal Oil seal Gland Pack Gland Pack Gland Pack Gland Pack Gland Pack Gland Pack
Power Required in KW 2.2 3.7 5.5 22.5 30 37.5 37.5 x 2 nos
Dimension (LxBxH) in mm 850x650x1200 1800x800x1300 1800x800x1300 2000x1150x1500 3000x1400x1700 3750x1650x1900 4600x2050x2200
Weight (Approx.)in kgs
 750 1100 1250 2500 4200 6000 8500

Specifications are subject to change as a part of continuous improvement
