Soaps & Detergents Machinery
 Products > Soaps & Detergents machinery > Plodder
Plodders are widely used in the manufacture of soaps, detergents, mosquito coils etc.
The plodders are made in different configurations viz.

      1. Single Worm Simplex Plodder
      2. Twin Worm Simplex Plodder
      3. Single Worm Duplex Vacuum Plodder
      4. Twin Worm Duplex Vacuum Plodder

  • The Worms are made of SS / MS / EN 8 constructions either casted or solidly fabricated
  • Pitch distances are variable and reducing fashion to produce compact soap bars
  • The Clearance between the worm and barrel will be 1-2 mm on all sides
  • The plodder is provided with jackets for cooling water circulation
  • Spider plates are provided with PTFE supports to ensure worms rest at centre
  • The end bearings are designed with adequate sturdiness for longer running life
  • Twin Worm plodders are provided with left and right gear drives through external or inbuilt mono-block gear boxes
  • Seamless or ERW pipes are used for barrel construction
  • End seals are fitted with glands for vacuum sealing
  • Vacuum chamber is made of SS 304 with toughened view glasses
  • The conical mouth is fitted with different output options

       1. Single mouth extrusion
       2. Double mouth extrusion
       3. Triple mouth extrusion
       4. Four mouth extrusion ( Flat straight / Twin lane equally diverted )

  • Heater is provided at the front edge of the conical mouth for better extrusion and  bar finish
  • Easy removal system for extrusion dies
  • Water ring vacuum pump is provided as optional accessory

Technical Specifications

Single Worm-Simplex
Model Aspro-SWP-50 Aspro-SWP-150 Aspro-SWP-1000 Aspro-SWP-1500 Aspro-SWP-2000
Diameter in Inch 4 6 8 10 12
Output (Kgs/Hr) Up to 50 * Up to 150 * Up to 1000 * Up to 1500 * Up to 2000 *
Contact Parts SS304/MS SS304/MS SS304/MS SS304/MS SS304/MS
Screw Worm Casted** Casted** Casted** Casted** Casted**
No. of Out puts 1 1 1 2 2
Power Required in KW 2.2KW 3.7KW 11.1KW 15KW 18.65KW
Dimension (LxBxH) 1000x580x1200 1662x650x1435 3400x1100x1500 3000x1200x1650 3600x1300x1700
Weight (Approx.) in Kgs 350 1130 2450 3700 3950






Single Worm-Duplex Vacuum Plodder
Model Aspro-SWDVP-50 Aspro-SWDVP-150 Aspro-SWDVP-1000 Aspro-SWDVP-1500 Aspro-SWDVP-2000
Diameter in Inch 4 6 8 10 12
Output (Kgs/Hr) NA Up to 150 * Up to 1000 * Up to 1500 * Up to 2000 *
Contact Parts NA SS304/MS SS304/MS SS304/MS SS304/MS
Screw Worm NA Casted** Casted** Casted** Casted**
Max No. of Out puts NA 1 1 2 2
Power Required in KW NA 7.5KW 22.5KW 30KW 37.5KW
Vacuum Pump-Optional NA 1.5 KW 2.2KW 3.7KW 5.2KW
Dimension (LxBxH) NA 2600x800x1900 4115x1100x2320 4550x1200x2600 5020x1300x3200
Weight (Approx.) in Kgs NA 2400 4250 6400 7800






Twin Worm-Duplex Vacuum Plodder
Model Aspro-TWDVP-50 Aspro-TWDVP-250 Aspro-TWDVP-2000 Aspro-TWDVP-4000 Aspro-TWDVP-6000
Technical Specifications 4 6 8 10 12
Single Worm-Simplex NA Up to 250 * Up to 2000 * Up to 4000 * Up to 6000 *
Model NA SS304/MS SS304/MS SS304/MS SS304/MS
Diameter in Inch NA Casted** Casted** Casted** Casted**
Output (Kgs/Hr) NA 1 1 3 4
Contact Parts NA 15KW 45KW 60KW 75KW
Screw Worm NA 1.5 KW 2.2KW 3.7KW 5.2KW
No. of Out puts NA 3600x850x2000 4115x1300x2320 4550x1400x2600 5020x1500x3200
Power Required in KW NA 6750 7500 9750 10500
Specifications are subject to change as a part of continuous improvement.
